DIFFGLASS XTREME

DIFFGLASS XTREME

Heavy-duty glass flake reinforced vinyl ester lining system for extreme corrosion protection.

DESCRIPTION:

DIFFGLASS XTREME SP is a heavy-duty lining system for concrete and steel substrates offering a unique combination of vinyl ester novolac resin with glass flake reinforcement and inert mineral fillers, producing a dimensionally stable coating with extremely low permeability.

Add to List

Applications

Product Specification

Bag house coating, acid storage tanks, chemical pumps, SOx and NOx gas environments



Technology Vinyl ester epoxy novolac
Chemical Type Vinyl Ester
Components Two-component
Cure Mechanism Room temperature cure
Temperature Range (°C) 20–170
Appearance – Base White
Appearance – Hardener Colorless
Appearance – Mixed Grey
Mix Ratio (Volume) 98.5 : 1.5
Mix Ratio (Weight) 98.5 : 1.5



Viscosity – Base Sprayable / Brushable
Viscosity – Hardener Liquid
Viscosity – Mixed Putty / Paste
Weight per Liter-Base (kg) 1.5
Weight per Liter-Hardener (kg) 0.85
Coverage 0.50 m² @ 1mm / kg



Compressive Strength 7000 – 7500 psi
Flexural Strength 8000 – 8500 psi
Hardness 80 – 85
Tensile Strength 4500 – 5000 psi
Elongation at Break (%) 1.5
Shear Strength 2000 – 2500 psi
Salt Spray Resistance 5000 hours
