DIE-BUILD-S

DIE-BUILD-S

Basic-coated electrode for highly alloyed, low-carbon weld metal with toughness, hot strength, and wear resistance at elevated temperatures.

PRODUCT DESCRIPTION:

• Machinable weld metal with excellent heat-crack resistance.
• Maintains toughness and wear resistance under temperature shocks.
• Withstands rapid cooling from 600–650 °C.
• Superior performance in Die Build series.

Add to List

Applications

STANDARD:

DIN EN 14700 E Fe 4-45-SPT

ALLOYING ELEMENTS:

C, SI, Mn, Ce, Mo, Ni, V, Co

HARDNESS:

41-47 HRC

PACKAGE SIZES:

5 KG – 20 KG



Size Welding Amperage
3.15 mm 85-115 A
4.00 mm 100-135 A
5.00 mm 130-160 A

Product Specification

• As-welded hardness: 41–47 RC.
• High toughness with good machinability.
• Secondary hardening capability through tempering.
• Excellent resistance to thermal shock and heat cracking.

• Low carbon, high alloy steel composition.
• Alloying elements: Chromium, Molybdenum,
Vanadium (for wear, toughness, and hot strength).
• Designed for secondary hardening with tempering.

• Remove fatigued/work-hardened material by gouging or grinding.
• Preheat base metal to 200–300 °C depending on die size/thickness.
• Use stringer beads, short arc, limited weave (≤3×electrode dia).
• For hardness control (38–45 RC), temper at 600–650 °C.
• Double tempering recommended; soak 1 hr per 20 mm section.

• Building large composite dies.
• Repair of steel industry dies.
• Chemical, cryogenic, and nuclear industry die repairs.
