SUPERALOY 2610
Special alloy electrode offering high hot strength and wear resistance from the first layer.
PRODUCT DESCRIPTION:
• Alloy-based electrode with Cr-Mo-Co
• Achieves hardness from first layer
• High wear and temperature resistance
• Machinable and impact tough
Applications
STANDARD:
DIN EN 14700 EFe 3-50-SPT
ALLOYING ELEMENTS:
Cr, Mo, Co
HARDNESS:
48 – 53 HRC
PACKAGE SIZES:
5 KG, 20 KG
TIP COLOR
SKY BLUE
COATING COLOR
LIGHT GREY
| Size | Welding Amperage |
|---|---|
| 3.15 mm | 95-130 A |
| 4.00 mm | 135-175 A |
| 5.00 mm | 160-200 A |
Product Specification
• Excellent red hardness
• Strong creep resistance
• Works under thermal shocks
• Tough, crack-resistant weld metal
• Chromium
• Molybdenum
• Cobalt
• Iron matrix
• Clean fatigued metal fully
• Use AC/DC+ polarity source
• Maintain short to medium arc
• Preheat as per tool grade
• Slow cool under blanket
• Stamping & trimming dies
• Steel mill table rolls
• Hot forging dies/formers
• Hot extrusion plungers
