DIFFUSALOY DIE 100
Cr-Ni-Mo electrode for forging die repair with excellent crack resistance under impact.
PRODUCT DESCRIPTION:
• Specially designed for die repairs
• Crack-resistant weld under heavy impact
• Suitable for high-strength tempered steels
• Ideal for cast steels of similar strength
Applications
STANDARD:
DIN EN 14700 EFe 3-45-SPT
ALLOYING ELEMENTS:
C, Si, Mn, Cr, Mo, Ni, V
HARDNESS:
42 – 45 HRC
PACKAGE SIZES:
5 KG, 20 KG
TIP COLOR
GREY
COATING COLOR
WHITE
| Size | Welding Amperage |
|---|---|
| 3.15 mm | 80-120 A |
| 4.00 mm | 120-150 A |
| 5.00 mm | 150-190 A |
Product Specification
• High toughness and strength
• Excellent friction resistance
• Withstands repeated impact loads
• All-position welding capability
• Chromium
• Nickel
• Molybdenum
• Tough martensitic matrix
• Remove fatigued/oxidized metal
• Use AC/DC+, short-medium arc
• Slight weave stringer beads
• Preheat high carbon steel to 250°C
• Air cool and peen deposits
• Forging dies, anvil blocks
• Hammer bases, sow blocks
• Cold rolling mill rolls
