DIFF EZ PRIME

DIFF EZ PRIME

Polymeric primer for EZ Slide system

PRODUCT DESCRIPTION:

Strong polymeric primer that penetrates
base surface and improves adhesion of EZ
Slide system.

Applications

Product Specification

TYPICAL APPLICATIONS:

Spiral chutes, pipe elbows, pump casings

PHYSICAL PROPERTIES

Technology	Polymer
Chemical Type	Epoxy
Components	Two-component
Cure Mechanism	Room temperature cure
Temperature Range (°C)	20–150
Appearance – Base	Colorless
Appearance – Hardener	Brown
Appearance – Mixed	Pale Yellow
Mix Ratio (Volume)	1.5:1
Mix Ratio (Weight)	1.7:1

UNCURED MATERIAL PROPERTIES

Viscosity – Base	Paste
Viscosity – Hardener	Paste
Viscosity – Mixed	Paste
Weight per Liter-Base (kg)	1.08
Weight per Liter-Hardener (kg)	0.925
Coverage	2.5 m² / kg @ 100µ

TYPIAL CURED PROPERTIES OF MATERIAL

Compressive Strength	7000 – 7500 psi
Flexural Strength	8000 – 8500 psi
Hardness	80 – 85
Tensile Strength	4500 – 5000 psi
Elongation at Break (%)	1.5
Shear Strength	2000 – 2500 psi
Salt Spray Resistance	5000 hours
