CORDIFF 62 OA

CORDIFF 62 OA

C-Cr-Nb alloyed wire providing excellent abrasion resistance via carbide-rich deposits.

PRODUCT DESCRIPTION:

• Tubular wire with C-Cr-Nb chemistry
• Forms hard chrome & niobium carbides
• Outstanding abrasion resistance
• Optimal performance with 2 layers

Add to List

Applications

STANDARD:

DIN EN 14700 T Fe 15-60-G

ALLOYING ELEMENTS:

C, Si, Mn, Cr, Nb

HARDNESS:

60-64 HRC

PACKAGE SIZES:

Spool- 15, 25 Kg
Drum- 200-250 Kg



DIA(Ø) 1.6 2.0 2.4 2.8
VOLTAGE 22-26 24-27 25-29 27-30
AMPERAGE 170-230 220-260 260-330 300-360

Product Specification

• High hardness weld layer
• Long-lasting wear protection
• Ideal for mineral abrasion
• Strong metallurgical bonding

• Chromium carbides
• Niobium carbides
• Austenitic matrix
• Hard complex phases

• For optimum results, perform welding in two layers.
• The resulting weld deposits cannot be heat treated, machined, or forged.
• When overlaying previously hard-faced surfaces, use a buffer layer of Cordiff 200K or Cordiff 250K before applying the final layer.

• Coal mining parts
• Cement plant rollers
• Steel industry wear plates
• Pelletizers & roller-mill tables
