CHROMADUR PLUS

CHROMADUR PLUS

Premium chromium-carbide wear plate for severe abrasive conditions

PRODUCT DESCRIPTION:

Chromadur Plus is a premium chromiumcarbide overlay wear plate designed for severe abrasive wear environments. It offers improved performance over standard chromium-carbide plates due to refined microstructure and optimized alloy composition.

Add to List

Applications

HARDNESS (HRC):

60–64 RC

MICROSTRUCTURE:

REFINED PRIMARY AND
EUTECTIC CHROMIUM
CARBIDES IN MARTENSITIC
MATRIX; MAX SERVICE

TEMPERATURE:

550°C

Product Specification

• Enhanced chromium-carbide overlay for severe abrasion
• Optimized alloying for increased toughness
• Long service life in extreme wear conditions
• Maintains hardness at elevated temperatures

• Prepare surface by abrasive blasting
• Weld overlay using controlled parameters for uniform deposition
• Select bead pattern based on application wear mode

Mining equipment liners; Cement plant chutes; Crusher components; Loader bucket liners; Sinter plant parts
